Road barrier Rh

The road barrier Rh is Rusthoven Verkeerstechniek’s most popular road barrier. This operator is available in three sizes: S, M and L.

This operator allows you to secure roads up to 15 meters in width. The Rh has been designed in accordance with VOBB regulations (NEN 6786) and is suitable for public roadways and tunnels throughout the Netherlands.

The RhU road barrier is designed with road users’ safety as the guiding principle. The operator continues to function under all circumstances, including strong winds or heavy frost. Nor is it a problem if the operator goes unused for extended periods or receives little maintenance.

Collisions are always a possibility with a barrier arm gate. That’s why we have designed our barrier arms to break off in case of a collision, causing minimal damage to the road user or the barrier arm operator. The barrier arm can then be replaced in fifteen minutes, ensuring traffic safety.

The barrier arm operator is made of galvanised steel and powered by an electric motor. All essential parts are easily accessible for inspection and maintenance. The Rh is provided with CE marking as standard.

Basic specifications

  • Time to open/close: < 10,2s
  • Diameter of arm: Ø136 / 100 mm
  • Power (motor): 0,25 kW

For more detailed information, please see the technical specifications.

Downloads

CE-certificate

CE logo

All operators will be delivered with a CE-certificate.
